Technical overview
| Power supply type | Office Series |
| ATX standard | ATX V2.2 |
| Connectors | |
| 20+4 pin mainboard | 1x 45 cm |
| 4+4 pin mainboard 12V | 1x 45 cm |
| PCI-Express | 1x PCI-Express 6 pin 45 cm |
| SATA | 4 (2x 45 / 2x 60 cm) |
| PATA | 2x 75 cm |
| FDD | 1x 90 cm |
| Mark of conformity | CE |
| Fan | 120 mm |
| PFC | active |
| Dimension h x w x d | 85 x 150 x 140mm |
| Weight (retail) | 1,367 kg |
| Power rating | 500W max. / peak |
| +3,3V | 20A |
| +5V | 22A |
| +12V1 | 15A |
| +12V2 | 15A |
| Temperature control for case fan | yes |
PDF:
Characteristics:
500W max. / peak
120mm fan
1x PCI-Express 6 pin connector
Incl. Active PFC (power factor correction for an efficient use of the spent energy) and all relevant safety circuitry
